Växel Vänster Wl15.

Växel Vänster Wl15. Längd 230 mm. Radie 873,5 mm.
Rocoline med banvall.
Skala: H0

Turnout left hand Wl15 with bedding, manually operated.
Length 230 mm (standard length), branch angle 15°, branch radius 873.5 mm, frog angle 10.8°, with pre-installed polarization.

An 8-mm spacer element (D8) is included for diagonal installation.

Suitable electric turnout drive: 42620 or 42624.

■ Frog and wheel guide completely revised
■ Prototypical passing of the frog possible
■ Groove width in the frog area according to NEM
■ Pre-installed polarisation of the turnout frog
